In terms of connectivity,
Wifi ProArt P16 H7606 features a more advanced Wi-Fi standard v7, providing faster and more reliable wireless connections compared to ProBook 455 G8 (v6).
Below, you'll find a Wi-Fi Versions Table, along with their release dates and speeds, to provide a brief overview of its development.
Wi-Fi Versions and Speeds
| Standard |
Speed |
Release Date |
Network |
Frequency Bands (GHz) |
| Wi-Fi 7 |
up to 40 Gbps (5 GB/s) |
2023 |
802.11be |
2.4, 5, 6 |
| Wi-Fi 6E |
up to 9.6 Gbps (1.2 GB/s) |
2020 |
802.11ax |
2.4, 5, 6 |
| Wi-Fi 6 |
up to 9.6 Gbps (1.2 GB/s) |
2019 |
802.11ax |
2.4, 5 |
| Wi-Fi 5 |
up to 6.93 Gbps (866.25 MB/s) |
2014 |
802.11ac |
2.4, 5 |
| Wi-Fi 4 |
up to 600 Mbps (75 MB/s) |
2009 |
802.11n |
2.4, 5 |
* Please note that the provided transfer rates are maximum theoretical values, and real-life performance may vary based on environmental factors.
USBBoth ProBook 455 G8 and ProArt P16 H7606 have USB-A ports. ProBook 455 G8 has 3x USB 3.2 USB-A ports, while ProArt P16 H7606 has 2x USB 3.2 USB-A ports.Both ProBook 455 G8 and ProArt P16 H7606 have USB Type-C ports. ProBook 455 G8 has 1x USB 3.2 USB Type-C ports, while ProArt P16 H7606 has 2x USB 4.0 USB Type-C ports.
Below, you'll find a table of USB ports, along with their release dates and speeds.
To mitigate the confusion caused by generation names, the USB Implementers Forum (USB-IF) suggests using marketing names like USB 5Gbps, USB 10Gbps, and so forth, based on their respective transfer rates.
USB Type and Speeds
| USB Type |
Version |
Speed |
Date |
Other Features/Explanations |
| USB4 |
Gen 4 (2.0) |
80 Gbps |
2022 |
Also known as USB 80Gbps |
| USB4 |
Gen 3×2 |
40 Gbps |
2019 |
Also known as USB 40Gbps |
| USB 3.2 |
3.2 Gen 2x2 |
20 Gbps |
2019 |
Double the data transfer rates of Gen 2 |
| USB 3.2 |
3.2 Gen 2 |
10 Gbps |
2017 |
Previously known as USB 3.1 |
| USB 3.2 |
3.2 Gen 1 |
5 Gbps |
2017 |
Previously known as USB 3.0 |
| USB 3.1 |
3.1 Gen 2 |
10 Gbps |
2013 |
Faster data transfer rates |
| USB 3.0 |
3.1 Gen 1 |
5 Gbps |
2010 |
SuperSpeed USB, improved data transfer rates |
| USB 2.0 |
2.0 |
480 Mbps |
2000 |
High-speed data transfer |
| USB 1.0 |
1.0 |
1.5 Mbps |
1996 |
Original USB standard |
ThunderboltNeither ProBook 455 G8 nor ProArt P16 H7606 has Thunderbolt port.
HDMIBoth ProBook 455 G8 and ProArt P16 H7606 feature an HDMI port. ProBook 455 G8 offers 1x HDMI 1.4, while ProArt P16 H7606 offers 1x HDMI 2.1.
Below, you'll find a comparison table detailing different HDMI versions, including their bandwidth, color depth, maximum resolution, and release dates. This information can be helpful in understanding the capabilities of each HDMI version and choosing the most suitable one for your needs.
HDMI Comparison Table
| HDMI Version |
Maximum Resolution |
Bandwidth (Gbps) |
Color Depth (bits) |
Release Date |
| HDMI 2.1-2.1b |
7680 x 4320 (8K) @ 60p 3840 x 2160 (4K) @ 120p |
48.0 |
48 |
2017 |
| HDMI 2.0-2.0b |
3840 x 2160 (4K) @ 60p |
18.0 |
48 |
2013 |
| HDMI 1.4-1.4b |
3840 x 2160 (4K) @ 30p |
10.2 |
48 |
2009 |
| HDMI 1.3-1.3a |
2560 x 1440 @ 60p |
10.2 |
48 |
2006 |
| HDMI 1.0-1.2a |
1920 x 1200 @ 60p |
4.95 |
24 |
2002 |
* Please note that the provided resolution values represent the maximum supported resolution, and actual display quality may depend on other factors such as source content and connected devices.
SD Card ReaderBoth ProBook 455 G8 and ProArt P16 H7606 come with an SD Card Reader for easy access to memory cards.
Audio JackBoth ProBook 455 G8 and ProArt P16 H7606 are equipped with a 3.5mm Audio Jack, providing seamless connection to headphones and speakers.
To summarize the connectivity and ports details, please refer to the table below to see them listed.
| Connectivity and Ports |
WiFi Standard
(latest: v7) |
v6
|
v7
|
Bluetooth
(latest: v6.2) |
v5.2
|
v5.4
|
USB-A
(latest: 3.2) |
3x USB 3.2 |
2x USB 3.2 |
USB Type-C
(latest: USB4 2.0) |
1x USB 3.2
|
2x USB 4.0
|
Thunderbolt
(latest: 5) |
No
|
No
|
HDMI
(latest: 2.1) |
1x HDMI 1.4 |
1x HDMI 2.1 |
Display Port
(latest: v2.0) |
No
|
No
|
| VGA |
No
|
No
|
| Fingerprint Sensor |
Optional
|
No
|
| Optical Drive |
No
|
No
|
| Audio Jack 3.5mm |
Yes
|
Yes
|
| Ethernet RJ45 |
Yes
|
No
|
| SD CardReader |
Yes
|
Yes
|
| Proprietary Charging Port |
Yes
|
Yes
|
